用于机载SAR的距离向波束赋形微带天线阵的研究
Study on the Microstrip Antenna Array for Airborne SAR System with the Shaped Beam in the Range Plane
-
摘要: 通过对宽测绘带的机载合成孔径雷达距离向回波特性的分析，推导出了天线距离向辐射赋形方向图表达式。利用Schelkunoff单位圆结合零限填充对天线阵进行综合，得到了天线各单元激励幅度和相位，并利用微带贴片天线阵列实现赋形波束方向图。该文用两种介质配置分别加工了实验样阵列，实验结果、仿真结果与理论综合结果三者吻合较好，从而证明了赋形方法正确，技术路线可行。Abstract: The characteristic of the echo of the wide swath airborne Synthetic Aperture Radar (SAR) is analyzed, then the expression of the shaped beam radiation pattern in the range plane of antenna is induced . The pattern is synthesized using the Schelkunoff unit circle method with null filling, and the exciting amplitude and phase of the 5 elements are given. The two sample microstrip arrays with different dielectric are fabricated, and the measured results are basically in accordance with the simulated and synthesized results. The valid conclusion of the synthesized and realized the shaped beam pattern can be drawn and the technology route is feasible.
-
魏钟铨. 合成孔径雷达卫星. 北京: 科学出版社，2001, 第1章.[2]王小青，郭琨毅，盛新庆, 朱敏慧. 距离向多孔径接收宽测绘带SAR成像方法的研究[J].电子与信息学报.2004, 26(5):739-745浏览[3]康行健. 天线原理与设计. 北京：国防工业出版社， 1995， 第6，7章.[4]肖疆，徐晓文，董涛. 多孔毁伤时赋形反射面天线辐射特性的研究. 电波科学学报 2003,18(6): 648-651.[5]乌拉比F T, 穆尔R K, 冯建超 著. 黄培康, 汪一飞 译. 微波遥感 (第二卷). 北京: 科学出版社, 1987: 第7章.[6]Shelkunoff S A. A mathematical theory of linear arrays. Bell System Technology Journal, 1943, 22 (1): 80-107.[7]鲍尔I J, 布哈蒂亚P 著. 梁联倬 等译. 微带天线. 北京：电子工业出版社，1985, 第1章.[8]Mailloux R J, Mcllvenna J F, Kernweis N P. Microstrip array technology. IEEE Trans. Antennas Propagation, 1981, AP-29(1): 25-37.[9]钟顺时. 微带天线理论与应用. 西安：西安电子科技大学出版社，1991, 第1章. -
