通用硬件模糊控制器研究
On the hardware realization of general fuzzy controller
-
摘要: 提出了一种基于多值逻辑电路的模糊控制器硬件实现方案,采用规则分时进行硬件模糊推理,不同规则的推理结果合并后形成模糊输出,经模糊判决后形成精确量输出。该方案的复杂性不受规则数量的影响,执行速度不受语言变量维数的影响,该方案通过改变存储器数据可以方便地调整隶属度函数和模糊控制规则,克服了硬件模糊控制器灵活性差这一重大缺陷,该方案便于以VLSI实现。Abstract: A new hardware realization methodology of fuzzy controller based on Multiple-Valued Logic (MVL) circuits is proposed. To the methodology, the hardware fuzzy inference process for different rule is executed in different time. The combination of the inference results of different rules makes fuzzy output, then it is changed to general output by defuzzification. According to this methodology, the complexity of the controller is free from the number of rules and the executive speed free from the dimension of fuzzy variables, furthermore, the choice of membership functions is free and the adjustment of fuzzy control rules is easy. The new methodology can be easily realized by using the very-large-scale-integration technique.
-
冯宏娟,等,直接修改控制规则的自调整模糊控制器,电子学报,1992,20(2),10-16.[2]王守臣,等,基于多值逻辑电路和二值PLA的硬件模糊控制器,电子学报,1998,26(8),86-88.[3]何平,等,模糊控制器的设计及应用,北京,科学出版社,1997,155 181,104[4]Zheng Tang,et al.,Alearning multiple-valuedlogic networks:algebra,algorithm and applications,IEEE Trans.on Computers,1998,47(2),247-251.[5]徐德,等,截断斜坡函数多值逻辑神经元,微电子学,2000,30(2),83-87.[6]诸静,等,模糊控制原理与应用,北京,机械工业出版社,1995,128. -
