GTEM室与开阔场的辐射测量之间关系研究
Correlation between gtem cell and open area test site in emission measurements
-
摘要: 该文详细推导了用电、磁偶极矩展开表示的电小尺寸辐射体在 GTEM室的辐射功率与开阔场中辐射场之间的理论关系,修正了 Lee理论中相应公式,并将理论结果与标准单极子辐射源实验结果进行了比较。结果表明两者符合的很好。这说明 GTEM室和开阔场辐射测量具有密切的相关性。对于电小尺寸的辐射体,GTEM室不仅可以用于 EMS测试,也可用于做 EMI测试。
-
关键词:
- GTEM室; 开阔场; 辐射测量
Abstract: This paper derives in detail the horizontal radiated electric fields from an elec-trically small radiator which may be well represented by the electric dipole and the magnetic moments, then the Lees corresponding formula are modified. Theoretical results compared with experimental data measured directly over OATS agree well. This shows that GTEM cell measurements are correlative with OATS emission measurements. For the electrically small radiator, GTEM cell may be used not only for EMS test but also for EMI test. -
P. Wilson, On the correlating TEM cell and OATS emission measurements, IEEE Trans. on Electromagnetic Compatibility, 1985, EMC-27(3), 137-142.[2]P. Wilson, On the correlating TEM cell and OATS emission measurements, IEEE Trans. on Electromagnetic Compatibility, 1995, EMC-37(1), 1-16.[3]Ae-Kyoung Lee, An algorithm for an advanced GTEM to ground plane correlation of radiated emission test, IEEE EMC Symposium, Seattle, 1996, 58-62.[4]任列辉,陈志雨,GTEM室与开阔场的辐射发射相关研究,电波科学学报,2002,17(1),74-77.[5]Julius Adams Stratton, Electromagnetic Theory, New York and London, McGRAW-HILL book company, 1941, 176-179, 235-237. -
