电大尺寸复杂结构腔体电磁散射的IPO/FEM混合法研究
Investigation on EM scattering by electrically large complex cavity using IPO/FEM hybrid method
-
摘要: 该文将物理光学迭代法(IPO)的子域连接法与矢量有限元法(FEM)相结合,提出了一种新的混合方法用于分析计算电大尺寸复杂结构腔体目标的电磁散射特性。对于腔体内部适合用高频方法处理的部分采用IPO方法分析;对于具有复杂结构和材料特性的部分,采用矢量有限元法进行研究,利用交界面上的连续性条件实现这两种方法的耦合。为了验证理论模型的正确性,该文对某一矩形空腔及底部加载金属台阶的腔体进行了分析,计算结果与文献数据以及用时域有限差分法所得结果一致,并具有很好的收敛效果。在此基础上,对底部加载介质层的复杂结构腔体进行了分析计算,结果表明这种混合方法对于分析电大尺寸复杂结构腔体的散射特性是行之有效的。Abstract: In this paper, a novel hybrid approach is proposed in which Iterative Physical Optics (IPO)subdomain splicing technique is combined with edge-based finite element method. It is applied to the analyses of electromagnetic scattering characteristics of electrically large complex cavities. IPO approach is applied for the region where it is suitable to use high frequency method; the edge-based finite element method is employed for the region where complex structures or complex materials are located. At the interface, the field continuous condition is applied to realize the coupling of the two regions. To verify the new approach, an open-ended empty rectangular cavity and cavity loaded with a metal cuboid are analyzed. The numerical results are in agreement with the published data and those obtained by FDTD. Good convergence behavior is observed. Moreover, complex cavities where three layers of lossy dielectric or a metal cuboid is loaded at the bottom are analyzed. The results show that the proposed hybrid approach is efficient for analyzing the electromagnetic scattering characteristic of electrically large complex cavity.
-
阮颖铮,空腔结构电磁散射分析方法研究,电波科学学报,1994,9(1),73-82.[2]P.H. Pathak, R. J. Burkholder, Mode, ray and beam techniques for analyzing the EM scattering by open-ended waveguide cavities, IEEE Trans. on AP., 1989, AP-37(5), 635-647.[3]P.H. Pathak, R. J. Burkholder, High-frequency electromagnetic scattering by open-ended waveguide cavities, Radio Sci., 1991, 26(1), 211-218.[4]王树民,李明之,王长清,GRE-FDTD混合法对二维矩形终端任意形状进气道RCS的计算,电子学报,2000,28(6),138-141.[5]Robert Lee, Tsc-Tong Chia, Analysis of electromagnetic scattering from a cavity with a complex termination by means of a hybrid ray-FDTD method, IEEE Trans. on AP, 1993, AP-41(11),1560-1569.[6]Liu Jian, Jin Jian-ming, A special higher order finite-element method for scattering by deep cavities, IEEE Trans. on AP., 2000, AP-48(5), 694-703.[7]F. Obelleiro, J. Luis Rodriguez, R. J. Burkholder, An iterative physical optics approach for analyzing the electromagnetic scattering by large open-ended cavities, IEEE Trans. on AP.,1995, AP-43(4), 356-361.[8]顾长青,舒永泽,徐金平,物理光学迭代法的子域连接法,电子学报,2001,29(3),420-422. [9]Tsc-Tong Chia, Robert J. Burkholder, Robert Lee, The application of FDTD in hybrid methods for cavity scattering analysis, IEEE Trans, on AP., 1995, AP-43(10), 1082-1089.
