金属截锥柱侧天线辐射场的研究
STUDY ON RADIATION FIELD OF ANTENNAS ON THE TRUNCATED CONE-CYLINDER
-
摘要: 根据实测的单元天线方向图,利用几何绕射理论,给出了金属截锥柱侧天线三维辐射场的一种有效的数值分析方法。这些公式同样适用于金属截柱或截锥。应用上述公式计算了截锥侧微带天线及其排阵的任意平面方向图,并与实测结果进行了比较,两者吻合良好。Abstract: On the basis of the experimental element pattern and GTD, an efficient numerical method for analyzing 3-D radiation field of antennas on the truncated cone-cylinder is presented. These formulas are also applicable to the truncated cylinder and cone. Examples are given on the calculation of 3-D radiation fields of microstrip antennas on the truncated cone. The results of calculations agree well with the experimental ones.
-
刘其中,宫德明,马澄波.电子学报,1990,18(5). 40-46.[2]刘其中,张野,王辉宁.电子学报,1992,20(9):93-95.[3]Pathak P H, Wang N. IEEE Trans. on AP, 1981, AP-29(4):609-622.[4]汪茂光.几何绕射理论.西安:西北电讯工程学院出版社,1985,60-93.[5][5][6]刘其中,马澄波,宫德明.西安电子科技大学学报,1991,18(3):45-53. -
