具有两节滤波器的速调管宽带输出段的设计方法
DESIGN CONSIDERATIONS OF THE TWO-STAGE-FILTER TYPE OUTPUT CIRCUIT OF BROADBAND KLYSTRONS
-
摘要: 本文从等效电路和微波网络理论出发,提出了具有两节滤波器的速调管宽带输出段的设计方法,根据该方法,在给定的阻抗实部R*下,可求得频宽最宽的一组设计参数。实验证明该方法是可行的。
-
关键词:
Abstract: In this paper, from the microwave network equivalent circuit point of view, we propose a design method of output circuit of broadband klystron which is made of two stage filters. According to this method, we can get a group of design parameters corresponding to the broadest bandwidth with given real part of interaction impedance. It is proved experimentally that this method is feasible. -
电子管设计手册编委会编,大功率速调管设计手册,国防工业出版社,1979年9月. -
