天线阵结构对非视距室内MIMO信道容量的影响

吕剑刚; 吕英华; 李云庄; 杜鹃

天线阵结构对非视距室内MIMO信道容量的影响

吕剑刚^{①;吕英华},
吕英华,
李云庄,
杜鹃

计量
- 文章访问数: 2335
- HTML全文浏览量: 97
- PDF下载量: 1058
- 被引次数: 0
出版历程
- 收稿日期: 2004-12-29
- 修回日期: 2005-06-21
- 刊出日期: 2006-09-19

Antenna Array Structures Effect on Capacity of Indoor NLOS MIMO Channel

摘要

摘要: 采用2维射线跟踪法分析了非视距室内环境中天线间隔、天线阵形对MIMO系统容量和互补累积分布函数(CCDF)的影响。结果表明随着天线间隔减小，MIMO系统容量降低。10%中断容量表明，天线间隔相同时，有独立同分布瑞利信道容量大于线性阵容量大于方阵容量或者圆形阵容量的关系。当天线间隔大于等于3 时，不同天线阵列阵形对容量影响非常小，此时i.i.d.瑞利信道理论容量几乎全部实现。当天线间隔小于等于1 时，天线阵列阵形对容量影响较大，矩形阵和圆形阵MIMO系统容量相差较小，但都显著小于线性阵列系统容量。在非视距的室内环境中，要实现最大的MIMO容量增益，设计天线阵列时应该对天线间隔和阵列阵形综合考虑。
- 无线通信; 多入多出; 射线跟踪法; 容量互补累积分布函数; 阵列结构; 非视距
Abstract: A 2-D shooting-and-bouncing ray-tracing (SBR) method is used to analyze the different antenna array structures effect on the capacity CCDF of indoor NLOS MIMO channel. The results show in NLOS indoor environments the less antenna interval is, the less MIMO channel capacities get. The results on 10% outage capacity show that there exist a fixed relationship that i.i.d Rayleigh channel capacity is larger than the capacity with linear antenna array which is larger than the capacity with rectangular antenna array or with circular antenna array. When antenna interval is equal to or larger than 3, antennas array structures affect the CCDF indistinctively and all the CCDF approach the theoretical i.i.d Rayleigh capacity, i.e. Telatar capacity. When antenna interval is equal to or less than 1, the CCDFS of MIMO system equipped with different antenna array structures changes remarkably. To obtain the MIMO capacity gains in indoor NLOS environment, antenna interval and antenna structure should be considered jointly when designing the antenna array.

HTML全文

参考文献(1)

Foschini G J, Gans M J. On limits of wireless communications in a fading environment when using multiple antennas[J].Wireless Personal Communications.1998, 6(3):311-335[2]Telatar I E. Capacity of multi-antenna Gaussian channels[J].Eur. Trans. Tel.1999, 10(6):585-595[3]Paularj A J, Gore D A, Babar R U, et al.. An overview of MIMO communicationsA key to gigabit wireless[J].Proc. IEEE.2004, 92(2):198-218[4]Gesbert D, Shafi M, Shiu D S, et al.. From theory to Practice: An overview of MIMO spac-time coded wireless systems[J].IEEE J. on Select. Areas Commun.2003, 21(3):281-302[5]Huang Y M, L Y H, Xu L. Improving a hybrid method ofindoor propagation modeling for wireless communications systems. The Journal of China University of Posts and Telecommunications, 2003, 10(3): 41-45.[6]Hampicke D, Landmann M, Schneider C, et al.. MIMO capacities for different antenna array structures based on double directional wideband channel measurements, Proceedings of VTC 2002, 1: 180-184.[7]Pohl V, Jungnickel V, Haustein T, et al.. Antenna spacing in MIMO indoor channels. IEEE VTC, 2002, 2: 749 -753.[8]Ghobadi C, Shepherd P R, Pennock S R. 2D ray-tracing model for indoor radio propagation at millimeter frequencies, and the study of diversity techniques. Proc.-H., 1998, 145( 4): 349-353.[9]Iskander M F, Yun Z. Propagation prediction models for wireless communication systems[J].IEEE Trans. on Microwwl. Tech.2002, 50(3):662-673[10]Burr A. Evaluation of capacity of indoor wireless MIMO channel using ray tracing. Proceeding International Zurich Seminar Broadband Communications, 2002: 28.1-28.6.[11]Tila F, Shepherd P R, Pennock S R. Theoretic capacity evaluation of indoor micro- and macro-MIMO systems at 5GHz using site specific ray tracing[J].Electron. Lett.2003, 39(5):471-472[12]季忠，黎摈洪, 王豪行等. 用射线跟踪法对室内电波传播进行预测. 电波科学学报，1999, 14(2): 160-165.[13]王一平，陈达章，刘鹏程. 工程电动力学. 西安：西北电讯工程学院出版社，1985.[14]Chuah C N, Tse D, Kahn J M, et al.. Capacity scaling in MIMO wireless systems under correlated fading[J].IEEE Trans. on Info. Theory.2002, 48(3):637-650[15]Ertel R B, Cardieri P, Sowerby K W, et al.. Overview of spatial channel models for antenna array communication systems. IEEE Personal Commu., 1998, 5: 10-22.[16]Biglieri E, Proakis J, Shamai S. Fading channels: information-theoretic and communications aspect[J].IEEE Trans. on Info. Theory.1998, 44(6):2619-2692
