6H－SiC MOS结构电特性及其辐照效应的研究
Study of the electric characteristics and radiation response of 6h-sic mos structure
-
摘要: 对SiC MOS结构辐照引起的电参数退化及其电特性进行了研究。结果说明:在氧化层电场较高时Fowler-Nordheim隧穿电流决定着SiC MOS结构的漏电流,当幅照栅偏压为高的正电压时,电离幅照对SiC MOS电容的影响会更明显,SiC MOS器件比Si器件具有好的抗辐照的能力,在58kGy(Si)的辐照剂量下,其平带电压漂移不超过2V。Abstract: The radiation response and electric characteristics of 6H-SiC MOS structure are studied with experiment. It is found that the main electronic conduction mechanism in the high field regions of the I-V characteristics is identified to be Fowler-Nordheim tunneling. The fact that ionization radiation effect becomes more notable at high oxide electric field indicates that the generation of radiation induced charge-centers near SiC/SiO2 interface and in gate oxide under high electric field is higher than that under low electric field. SiC MOS structure has a more significant tolerance to y rays than Si MOS structure. Flatband voltage shift of SiC MOS capacitor is less than 2V under radiation of 58kGy(Si).
-
P. Friedrichs, E. P.Burte, Dielectric strength of thermal oxides on 6H-SiC and 4H-SiC, Appl.Phys. Lett., 1994, 65(13), 1665-1667.[2]M. Yoshikawa, Y. Morita, Gamma-ray irradiation effects on cubic silicon carbide metal-oxidesemiconductor structure, Springer Proceedings in Physics, Vol.71, Amorphous and Crystaline Silicon Carbide Ⅳ, 1992, 393-398.[3]M. Yoshikawa, K. Saitoh, T. Ohshima, Generation mechanisms of trapped charges in oxide layers of 6H-SiC MOS structures irradiated with gamma-rays, Int. Conf. on Silicon Carbide, III-Nitrides and Related Materials, Switzerland, 1998, 1017-1020.[4]J.B. Casady, J. D. Cressler, Direct current characterization of depletion-mode 6H-SiC MOSFETs form 294 to 723K, Solid State Electronics, 1996, 39(6), 777-784.[5]D. Alok, P. K. Mclarty, Electrical properties of thermal oxide grown on n-type 6H-silicon carbide,Appl. Phys. Lett., 1994, 64(21), 2845-2848.[6]郭维廉,硅～二氧化硅界面物理,北京,国防工业出版社,1989,第3章.[7]宋钦岐,MOS电容的电离辐照效应及其加固技术研究,抗核加固,1986,3(1),33-42.[8]赖祖武,抗辐射电子学-辐射效应及加固原理,北京,国防工业出版社,1998,46-83. -
