1-18GHz微带巴伦双平衡混频器
A 1-18GHz MICROSTRIP BALUN DOUBLE BALANCED MIXER
-
摘要: 本文介绍了一种微带巴伦多倍频程微波集成双平衡混频器。它是由宽带微带巴伦和二极管电桥组成。这种微带巴伦双平衡混频器显示了良好的噪声特性和隔离特性。在1-18GHz工作频率范围内,最大双边带噪声系数为8.7dB,平均双边带噪声系数约6dB;本振端一信号端、本振端一中频端隔离度均大于15dB。
-
关键词:
- 宽带混频器; 双平衡混频器; 微带巴伦
Abstract: A multi-octave microstrip balun double balanced mixer has been developed. This mixer which is consisted of a broad-band balun and a diode ring exhibits extremely encouraging performance. Within the multi-octave bandwidth from 1 to 18 GHz, the average DSB noise figure is 6 dB, and the maximum DSB noise figure is 8.7 dB, and both LO-RF and LO-IF isolations are more than 15 dB. -
U. S. Patent, 3,652,941, Feb. 1970.[2]M. A. Smith.[J].A. M. Pavio, IEEE IntI Microwave Symp. Digest, St. Louis, U. S. A.1985,:-[3]王宗欣,电子技术,,1980年,第4期,第10-13页.[4]王新,邓少范,宽带双面微带巴伦线的设计,1985年全国微波会议论文,西安,1985年.[5]吴万春等编,微波网络及其应用,国防工业出版社,1980年,251.
