矩形波导中小导体异物的影响
THE EFFECT OF A SMALL CONDUCTING FOREIGN BODYIN THE WAVEGUIDE
-
摘要: 本文利用矩形谐振腔中的教扰公式结合准静态近似,导出了矩形波导中小导体异物的等效串联电抗和并联电纳。求出了反射系数,传输相移及功率容量降低的表示式.这种表示式在试验中表明是适合的。Abstract: The equivalent series reactance and parallel susceptance of a small conclucring foreign body in the rectangular waveguides are derived by using perturbational formula in the rectangular cavity and combining with quasi-static approximation. The expressions of its reflection coefficient, transmission phase displacement and power carrying capacity reduction are also given. The expressions are shown that is satisfactory in experiment.
-
J. Hinken, IEEE Trans. on MTT, MTT-28(1980)7, 711-744.[2]林为干,成都电讯工程学院学报,29(1983)1,12-23;中国科学,A集,27(1984)2, 184-195.[3]王典成,电磁场理论与微波技术,科学出版社,1986年.[4]哈林登著,孟侃译,正弦电磁场,上海科学出版社,1964年.[5]А.Л.Фельдштейн,Правочник по Элементам Волноводной Техники Москва,(1963). -
