高重复频率高压脉冲发生器
A HIGH REPETITION-RATE HIGH VOLTAGE PULSEGENERATOR
-
摘要: 正 (一)引言 激光电光调制技术以及其它一些物理实验需要重复频率高、电压幅度高、宽度可变的快速高压矩形脉冲发生器。根据需要,我们设计了双臂式充放电电路。同时调试安装了两种规格的高压脉冲发生器。 采用国产FM-30束射四极管作为高压充放电管,达到的指标如下: (1)脉冲幅度:最高5kV(250V5kV连续可调,零电位为250V)。 (2)前后沿时间:负载电容为100pF时,0.5s;负载电容为200pF时,0.8s
-
关键词:
Abstract: In this paper, a double arm charge-discharge circuit is described. A high repetition-rate high voltage and variable width rectangular pulse has been obtained. Its technical data are as follows: Its amplitude is 600 V-8 kV continuously adjustable; The maximum repetition-rate is 30kHz; The rise and fall time is less then 1.5s when the load capacity is 56 pF, less then 1.8s when the load capacity is 112 pF; The pulse duration ratio is 1:10-1:1 continuously adjustable. Theoretical analysis for the circuit, has been made. -
J. Millman and H Taub著,杨龙生等译,脉冲与数字电路,科学出版社,1963年,第229页.
