任意电压源输入下开关电容网络分析的回路电荷法
A LOOP CHARGE APPROACH FOR THE ANALYSIS OF SWITCHED-CAPACITOR NETWORKS WITH ARBITRARY VOLTAGE SOURCE INPUTS
-
摘要: 本文提出了一种适用于开关电容网络精确分析的回路电荷法。该网络包含电容、独立电压源,开关和零极子(nullors)。该方法适用于任意K相开关状态,能处理任意的连续时间和离散时间输入。用回路电荷法,还导出了用输入电压表示电容电压的精确表达式。
-
关键词:
- 开关电容网络; 回路电荷法; CAA
Abstract: A loop charge approach is presented for the exact analysis of switched-capacitor networks containing capacitors, independent voltage sources, switches and nullors. t allows for arbitrary K-phase switching situations. And both arbitrary continuous time and liscrete time inputs are handled. By. means, of loop charge approach, exact formulations of apacitor voltages are derived in terms of the input voltages. -
C. F. Kurth, G. S. Moschytz, IEEE Trans. on CAS, CAS-26(1979), 93-104.[2]Y. P. Tsividis, IEEE Trans.on CAS, CAS-26(1979), 935-946.[3]M. L. Liou, Y. L. Kuo, IEEE Trans. on CAS, CAS-26(1979), 213-223.[4]J. Vandewalle, H. J. De Man, J. Rabaey, IEEE Trans. on CAS, CAS-28(1981), 186-195.[5]S. C. Fang, Y. P. Tsividis, O. Wing, IEEE Trans. on CAS, CAS-31(1984), 968.[6]L. T. Bruton, G. R. Bailey, G. Battacharjee, Loop Equation Formulatiotn far Switched CapacitorNetworks Containing Nullors, in 1982 IEEE Int. Symp. on CAS (Rome), pp. 29-32.[7]M. L. Liou, Y. L. Kuo, C. F. Lee, Proc. IEEE, 71(1983), 907-1005.[8]E. Hokenek, G. S. Moschytz, Proc. IEE, Pt. G. 127(1980), 226-241.[9]L. T. Bruton, G. R. Bailey, G. Battacharjee, Int. J. Circuit Theory Appl., 11(1983), 57-72. -
