双六端口网络分析仪的L校准法和系统的测量误差分析
L CALIBRATION FOR DUAL-SIX-PORT NETWORK ANALYZER AND ANALYSIS OF SYSTEM MEASURING ERROR
-
摘要: 本文提出了仅用一段传输线校准双六端口网络分析仪的新方法L校准法。用此方法,传输线电长度无需确知。详细分析了双六端口网络分析仪使用非理想隔离器产生的误差,给出了系统工作于准理想隔离状态所需的隔离度。
-
关键词:
- 微波测量; 双六端口网络分析仪; 校准
Abstract: A new method-L calibration technique for calibrating the duali-six-port network analyzer is proposed. Usinf this method a section of transmission line is needed only, and its length is not necessary to be known accurately. The measuring errors introduced by non-ideal isolators are discussed, and the degree of isolation needed for the system working in the quasi-ideal condition is given. -
G. F. Engen, IEEE Trans. on MTT, MTT-26(1978)12, 951-957.[2]D. Woods, Proc. IEE. 126(1979)2, 221-228.[3]P. I. Somlo, J. D. Hunter, IEEE Trans. on MTT, MTT-30(1982)2, 186-192.[4]S. H. Li, R. G. Bossio, IEEE Trans. on MTT, MTT-30(1982)7, 1085-1090.[5]C. A. Hoer, IEEE Trans. on MTT, MTT-25(1977)12, 1070-1074.[6]G. F. Engen, C. A. Hoer, IEEE Trans. on MTT, MTT-27(1979)12, 987-992.[7]H. M. Cronson, L. Susmen, IEEE Trans. on MTT, MTT-29(1981)3, 372-378.[8]孙稼,电子学报,12(1984)6,6-10.[9]阮成礼,中国科学,A辑,1987年,第2期,第201-210页.[10]S. H. Li, R. G. Bossio, IEEE Trans. on IM, IM-31(1982)1, 40-43.[11]申东娅,电子科技大学硕士研究生论文,成都,1988年. -
