基于叠加训练序列和低复杂度频域Turbo均衡的时变水声信道估计和均衡

杨光; 丁寒雪; 郭庆华; 颜琪; 王辛杰

doi:10.11999/JEIT200315

基于叠加训练序列和低复杂度频域Turbo均衡的时变水声信道估计和均衡

doi: 10.11999/JEIT200315

1.
青岛理工大学信息与控制工程学院青岛 266520
2.
伍伦贡大学电气计算机与电信工程学院伍伦贡 2522

基金项目: 国家自然科学基金(61771271)，山东省自然科学基金面上项目(ZR2020MF010, ZR2020MF001)，青岛市源头创新计划-青年专项(19-6-2-4-cg)，山东省高等学校科学技术(J18KA315)

详细信息

作者简介:
杨光：男，1981年生，博士，讲师，研究方向为水声通信

丁寒雪：女，1998年生，硕士生，研究方向为水声通信

郭庆华：男，1978年生，博士，副教授，IEEE高级会员，研究方向为水声通信和无线通信

颜琪：女，1996年生，硕士生，研究方向为水声通信

王辛杰：男，1980年生，博士，讲师，研究方向为水声通信

通讯作者:
丁寒雪　edit231@163.com

中图分类号: TN929.3
计量
- 文章访问数: 1235
- HTML全文浏览量: 415
- PDF下载量: 105
- 被引次数: 0
出版历程
- 收稿日期: 2020-04-28
- 修回日期: 2020-12-09
- 网络出版日期: 2021-01-04
- 刊出日期: 2021-03-22

Estimation and Equalization of Time-varying Underwater Acoustic Channel Based on Superimposed Training and Low-complexity Turbo Equalization in Frequency Domain

1.
School of Information and Control Engineering, Qingdao University of Technology, Qingdao 266520, China
2.
School of Electrical, Computer and Telecommunications Engineering, University of Wollongong, Wollongong 2522, Australia

Funds: The National Natural Science Foundation of China (61771271), The General Project of Natural Science Foundation of Shandong Province (ZR2020MF010, ZR2020MF001), Qingdao Source Innovation Program - Special Project for Young Scholars (19-6-2-4-cg), Shandong Province Higher Educational Science and Technology Program (J18KA315)

摘要

摘要: 针对时变水声信道估计和均衡问题，该文提出基于叠加训练序列(ST)和低复杂度频域Turbo均衡(LTE)的时变水声信道估计和均衡(ST-LTE)算法。基于叠加训练序列方案，将训练序列和符号线性叠加，使得训练序列和符号信道信息一致；基于最小二乘算法，进行信道估计。基于频域训练序列干扰消除技术，在频域消除训练序列对符号的干扰；基于频域线性最小均方误差(LMMSE)均衡算法，通过先验、后验、外均值和方差的计算，实现低复杂度信道均衡(符号估计)；基于Turbo均衡算法，软重构叠加训练序列和更新信道估计，进行均衡器和译码器的信息交换，利用编码冗余信息，大幅度提升信道均衡性能。进行仿真、水池静态通信试验(通信频率12 kHz，带宽6 kHz，采样频率96 kHz，符号传输速率4.8 ksym/s，训练序列和符号的功率比为0.25:1)和胶州湾运动通信试验(通信频率12 kHz，带宽6 kHz，采样频率96 kHz，符号传输速率3 ksym/s，训练序列和符号的功率比为0.25:1)，仿真和试验结果验证了所提算法的有效性。
- 运动水声通信 /
- 时变水声信道 /
- 叠加训练序列 /
- 低复杂度频域均衡 /
- Turbo均衡
Abstract: To solve the problems of time-varying underwater acoustic channel estimation and equalization, an estimation and equalization algorithm of time-varying underwater acoustic channel based on Superimposed Training (ST) and Low-complexity Turbo Equalization (LTE) in frequency domain (ST-LTE) is proposed. Based on the ST scheme, the training sequence and symbols are linearly superimposed to make the channel information of the training sequence and symbols consistent; Based on the least square algorithm, channel estimation is performed. Based on the interference elimination technique of training sequence in frequency domain, the interference of training sequence on symbols is eliminated in frequency domain; Based on the Linear Minimum Mean Square Error (LMMSE) equalization algorithm in frequency domain, the low-complexity channel equalization (symbol estimation) is realized by the calculation of prior, posterior, extrinsic mean and variance; Based on the Turbo equalization algorithm, soft reconstruction of superimposed training and update of channel estimation are conducted, the information exchange between equalizer and decoder is also carried out and the performance of channel equalization is extremely improved by using coding redundancy information. Simulation, static communication experiment in a pool (communication frequency is 12 kHz, bandwidth 6 kHz, the sampling frequency 96 kHz, the transmission rate of symbols 4.8 ksym/s and the power ratio of the training sequence on symbols 0.25:1) and moving communication experiment in Jiaozhou Bay (communication frequency is 12 kHz, bandwidth 6 kHz, the sampling frequency 96 kHz, the transmission rate of symbols 3 ksym/s and the power ratio of the training sequence on symbols 0.25:1) are carried out and simulation and experimental results verify the effectiveness of the proposed algorithm.
- Moving underwater acoustic communication /
- Time-varying underwater acoustic channel /
- Superimposed Training (ST) /
- Low-complexity equalization in frequency domain /
- Turbo equalization

HTML全文

图 1 基带通信系统

下载: 全尺寸图片幻灯片

图 2 Turbo均衡

下载: 全尺寸图片幻灯片

图 3 接收信号结构

下载: 全尺寸图片幻灯片

图 4 水声信道的响应

下载: 全尺寸图片幻灯片

图 5 解码误码率

下载: 全尺寸图片幻灯片

图 6 水池试验

下载: 全尺寸图片幻灯片

图 7 胶州湾试验

下载: 全尺寸图片幻灯片

图 8 胶州湾试验结果

下载: 全尺寸图片幻灯片

参考文献(18)

SONG Aijun, STOJANOVIC M, and CHITRE M. Editorial underwater acoustic communications: Where we stand and what is next?[J]. IEEE Journal of Oceanic Engineering, 2019, 44(1): 1–6. doi: 10.1109/JOE.2018.2883872

YANG T C. Properties of underwater acoustic communication channels in shallow water[J]. The Journal of the Acoustical Society of America, 2012, 131(1): 129–145. doi: 10.1121/1.3664053

CHEN Zhenrui, WANG Jintao, and ZHENG Y R. Frequency-domain turbo equalization with iterative channel estimation for MIMO underwater acoustic communications[J]. IEEE Journal of Oceanic Engineering, 2017, 42(3): 711–721. doi: 10.1109/JOE.2016.2600106

TADAYON A and STOJANOVIC M. Iterative sparse channel estimation and spatial correlation learning for multichannel acoustic OFDM systems[J]. IEEE Journal of Oceanic Engineering, 2019, 44(4): 820–836. doi: 10.1109/JOE.2019.2932662

ZHOU Yuehai, SONG Aijun, TONG F, et al. Distributed compressed sensing based channel estimation for underwater acoustic multiband transmissions[J]. The Journal of the Acoustical Society of America, 2018, 143(6): 3985–3996. doi: 10.1121/1.5042362

YIN Jingwei, YANG Guang, HUANG Defeng, et al. Blind adaptive multi-user detection for under-ice acoustic communications with mobile interfering users[J]. The Journal of the Acoustical Society of America, 2017, 141(1): EL70–EL75. doi: 10.1121/1.4974757

葛威, 殷敬伟, 杨光, 等. 载波频率不一致且频谱严重交叠干扰下的盲自适应多用户检测试验研究[J]. 兵工学报, 2019, 40(2): 353–360. doi: 10.3969/j.issn.1000-1093.2019.02.015

GE Wei, YIN Jingwei, YANG Guang, et al. Experimental research on blind adaptive multiuser detection algorithm with different carrier frequencies and severe overlapping interference of spectra[J]. Acta Armamentarii, 2019, 40(2): 353–360. doi: 10.3969/j.issn.1000-1093.2019.02.015

YIN Jingwei, GE Wei, HAN Xiao, et al. Frequency-domain equalization with interference rejection combining for single carrier multiple-input multiple-output underwater acoustic communications[J]. The Journal of the Acoustical Society of America, 2020, 147(2): EL138–EL143. doi: 10.1121/10.0000711

景连友, 何成兵, 张玲玲, 等. 水声通信中基于软判决的块迭代判决反馈均衡器[J]. 电子与信息学报, 2016, 38(4): 885–891. doi: 10.11999/JEIT150669

JING Lianyou, HE Chengbing, ZHANG Lingling, et al. Iterative block decision feedback equalizer with soft detection for underwater acoustic channels[J]. Journal of Electronics &Information Technology, 2016, 38(4): 885–891. doi: 10.11999/JEIT150669

唐怀东, 朱敏, 武岩波. 一种水声通信Turbo均衡中的软迭代信道估计算法[J]. 电子与信息学报, 2013, 35(3): 677–682. doi: 10.3724/SP.J.1146.2012.00820

TANG Huaidong, ZHU Min, and WU Yanbo. An algorithm of soft iterative channel estimation for turbo equalization of underwater acoustic communication[J]. Journal of Electronics &Information Technology, 2013, 35(3): 677–682. doi: 10.3724/SP.J.1146.2012.00820

TAO Jun. DFT-precoded MIMO OFDM underwater acoustic communications[J]. IEEE Journal of Oceanic Engineering, 2018, 43(3): 805–819. doi: 10.1109/JOE.2017.2735590

QIN Zhen, TAO Jun, WANG Xiaoyan, et al. Direct adaptive equalization based on fast sparse recursive least squares algorithms for multiple-input multiple-output underwater acoustic communications[J]. The Journal of the Acoustical Society of America, 2019, 145(4): EL277–EL283. doi: 10.1121/1.5096630

奚钧壹, 鄢社锋, 徐立军, 等. 水声通信系统中双向turbo均衡算法[J]. 声学学报, 2018, 43(5): 771–778. doi: 10.15949/j.cnki.0371-0025.2018.05.006

XI Junyi, YAN Shefeng, XU Lijun, et al. Bidirectional turbo equalization for underwater acoustic communications[J]. Acta Acustica, 2018, 43(5): 771–778. doi: 10.15949/j.cnki.0371-0025.2018.05.006

XI Junyi, YAN Shefeng, and XU Lijun. Direct-adaptation based bidirectional turbo equalization for underwater acoustic communications: Algorithm and undersea experimental results[J]. The Journal of the Acoustical Society of America, 2018, 143(5): 2715–2728. doi: 10.1121/1.5036730

XI Junyi, YAN Shefeng, XU Lijun, et al. Frequency-time domain turbo equalization for underwater acoustic communications[J]. IEEE Journal of Oceanic Engineering, 2020, 45(2): 665–679. doi: 10.1109/JOE.2019.2891171

HAN Jing, CHEPURI S P, ZHANG Qunfei, et al. Iterative per-vector equalization for orthogonal signal-division multiplexing over time-varying underwater acoustic channels[J]. IEEE Journal of Oceanic Engineering, 2019, 44(1): 240–255. doi: 10.1109/JOE.2017.2787898

QIN Xiangzhao, QU Fengzhong, and ZHENG Y R. Bayesian iterative channel estimation and turbo equalization for multiple-input-multiple-output underwater acoustic communications[J]. IEEE Journal of Oceanic Engineering, 2021, 46(1): 326–337. doi: 10.1109/JOE.2019.2956299

GUO Qinghua, HUANG Defeng, NORDHOLM S, et al. Iterative frequency domain equalization with generalized approximate message passing[J]. IEEE Signal Processing Letters, 2013, 20(6): 559–562. doi: 10.1109/LSP.2013.2256783
