重入式双路旋转交连的研究
DEVELOPMENT OF REENTRANT TWO WAY ROTARY JUNCTOR
-
摘要: 本文介绍一种新颖的双路旋转交连,一路设计在S波段,另一路设计在P波段。S波段交连的电压驻波比为:在1.2～4.4GHz频带内小于1.2,P波段交连采用重入式谐振腔结构,以使交连长发缩短。两路交连的总长度接近/4,满足了特定的小尺寸要求。Abstract: A novel two way rotary junctor is presented. One way of the rotarv junctor is designed at S band, and another way is designed at P band. The VSWR for S band rotary junctor is less than 1.2 in the 1.2-4.4 GHz frequency range. A reentrant resonant cavity is used for the design of the P band roiary junctor in order to reduce the length of the rotary junctor. The total length of two way rotary junctor is /4 approximately. It satisfies the needs for the especially small size.
-
J.R. Whinnery, H.W. Jamieson, Proc. IRE, 82(1944)11,695-711.[2]J.R. Whinnery, H.W. Jnmieson, Proc. IRE, 32(1944)Z,98-115. -
