悬置微带线的频率特性
FREQUENCY CHARACTERISTICS OF SUSPENDED MICROSTRIP LINE
-
摘要: 正 (一)引言 随着微波集成电路的飞跃发展,微带线得到了日益广泛的应用。为了减小其损耗及使其能用于更高的频率,进一步提出了悬置微带线,如图1所示
-
关键词:
Abstract: The stlspended microstrip line is used widely in the microwave integrated circuits due to its low loss property and large size. The frequeney eharacteristics of suspended microstrip lines are analyzed by using the spectral domain immittance approach. The characteristie impedance and relative guided wavelength curves are given for different dielectric materials. -
H. E. Brenner, Microwaves, 7, 9, pp. 38-45, Sept. 1968.[2]E. Yamashita et al., IEEE Trans. on MTT, MTT-18 (1970), 238.[3]J. L. Smith, IEEE Trans. on MTT, MTT-19 (1971), 424.[4]T. Itoh, IEEE Trans. on MTT, MTT-28(1980), 733.[5]Y.C.Shi T. Itoh, Electronics Letters, 18 (1982), 538.[6]周文表,宽边侧边耦合多微带线的频率特性,微波通信技术会议,泉州,1984. -
