摘要:
文中提出一个V/Q变换的广义跨导概念,并应用在开关电容阻抗模拟中。使用V/Q变换器,可以用电压传递函数实现所希望的阻抗函数。由此概念出发,分别导出了前差FD,后差BD和双线性S/Z变换的三种接地开关电容频变负阻SC-FDNR电路。如果所选用的电压传递函数电路对杂散电容不灵敏,那么实现的模拟阻抗电路对杂散电容也是不灵敏的。作为文中的一个例子,用FD-FDNR电路组成一个谐振回路,实验表明其频响特性与理论分析相一致。
Abstract:
A concept of general transconductance of V/Q (voltage/charge) transformation i.. proposed, and applied to the simulation of switching capacitance impedance. By Using V/Q transverter, the expected impedance function can be implemented by means of volrage transfer function. Starting from this concept, the switched capacitor-FDNR (frequency dependent negative resistor) circuits of three kinds of S/Z transformation (i.e. forward differential SfZ transformation, backward differential S/Z transformation, bilinear S/Z transformation) are respectively deduced. If the selected voltage transfer function circuit is not sensitive to stray capacitance, then the implemented simulation impedance circuit is also not sensitive to stray capacitance. As an example, a resonant loop is composed of forward differential FDNR circuit. The experiments show that the characteristics of its frequency response coincide with the theoretical analysis.
