压控振荡器的计算机辅助设计
COMPUTER AIDED DESIGN FOR VOLTAGE CONTROL OSCILLATOR
-
摘要: 本文从准正弦的方法导出了变容二极管调谐的耿氏二极管压控振荡器的电路方程。对非线性元件作了专门的处理,得到了一个通用的计算机程序,这个程序可以计算小信号和大信号的静态调制特性,也可以计算动态特性和各参量对过渡过程的影响。
-
关键词:
Abstract: A set of eqaations for varactor tuning Grunn Diode Oscillator is derived by quasi-sinusoidal method. By special treatment of the nonlinear element, a program is obtained. With this program the small signal and large signal statistic tuning performance, dyna-mic behavior and transient response can be calculated. -
VCO Technology, Final Report, Feb. 1979, EPL, University of Michigan.[2]D. F. Peterson, IEEE Trans. on MTT, MTT-23(1980), 110.[7]L. Gustafsson et al., IEEE Trans. on MTT, MTT-20(1972), 402.[8]宋文淼,微波电路的计算机辅助设计,中国科学院电子学研究所1982年科学技术报告会. -
