微带传输线特性的数值分析
THE NUMERICAL ANALYSIS OF THE PROPERTIES OF MICROSTRIP TRANSMISSION LINES
-
摘要: 本文应用混合模有限元方法分析和计算了微带传输线的各种特性,包括特性阻抗、速度比、色散特性以及带厚的影响,并与有关文献结果作了比较。结果表明,有限元法是对微带传输线进行数值分析的有效方法。
-
关键词:
- 微带传输线; 有限元法; 色散特性
Abstract: A numerical analysis is presented in terms of finite element of hybrid-mode propagation characteristics in microstrip transmission lines, which include characteristics impedance, velocity ratio, dispersion characteristic and the effect of strip thickness. The results of calculation are compared with previous approximate calculations. It is shown that the finite-element method is an efficient numerical analysis for microstrip transmission lines. -
H. A. Wheeler, IEEE Trans. on MTT, MTT-13(1965)2, 172-185.[2]N. Alexopoulos, IEEE Trans. on MTT, MTT-33(1985)10, 847-881.[3]A-M. A. El-Sherbiny, IEEE Trans. on MTT, MTT-29(1981)12,1261-1266.[4]廖承愚,微波技术基础,国防工业出版社,北京,1984年,第139-188页.[5]P. Daly, IEEE Trans. on MTT, MTT-18(1971)1, 19-25.[6]H. E. Green, IEEE Trans. on MTT, MTT-13(1965)5,676-692.[7]Z. Pantic and R. Mittra, IEEE Trans. on MTT, MTT-34(1986) 11, 1096-1103.[8]N. Mabaya and P. E. Lagasse, IEEE Trans. on MTT, MTT-29(1981)6, 600-605.[9]P. Silvester, IEEE Trans. on MTT, MTT-17(1969)4, 204-210.[10]M. Kobayashi, F. Ando, IEEE Trans. on MTT, MTT-35(1987)2, 101-105. -
