L波段相对论速调管束流实验研究
STUDY ON CURRENT OF L-BAND RELATIVISTIC KLYSTRON AMPLIFIERS
-
摘要: 介绍在L波段强流相对论速调管研究中,强流相对论短脉冲空心电子束的产生、传输、束流调制及其诊断等方面的初步实验研究情况。在直线感应加速器上,利用66mm、壁厚3mm的石墨空心阴极,加上约5kGs的准直流引导磁场,引出了约500kV、4.5kA、脉宽100ns、54.5mm、厚度4.5mm的空心电子束。注入500kW的微波调制,束流经过输入腔后,得到了约6％的最大基波电流调制深度,经过中间腔后,得到了约23％的基波电流调制深度。Abstract: Emission, translation, modulation and diagnosis of short pulse intense relativistic hollow electron beams (IREBs) of a L-band relativistic klystron amplifier are described in this paper. The hollow electron beams about 500kV, 4.5kA, diameter 54.5mm, thickness 4.5mm are obtained, and 6% of beam current modulation is gotten after the electron beams get through the input cavity gap, as well as 23% of beam current modulation is gotten after the electron beams get through the idler cavity gap.
-
Friedman M,Krall J, et al. Externally modulated intense relativistic electron beams. J.Appl.Phys. 1988,64(7): 3353-3379.[2]Friedman M, Serlin V. Present and development of high power RKA. SPIE Intense microwave and particle beams 1992(1629):1-7.[3]Fazio M V, Haynes W B, Carlsten B E. A 500MW lp,s pulse length high current relativistic klystron[J].IEEE Trans. on Plasma Science.1994, 22(5):740-749[4]黄华,王平山,甘延青,等.L波段相对论速调管放大器初步研究.强激光与粒子束,1998, 10(1): 135-139.[5]R.B.米勒著,刘锡三,等译.强流带电粒子束物理学导论.北京原子能出版社,1990: 21-25.[6]吴中发,王玉芝,黄益新.脉冲磁场中波导涡流影响的数值模拟.强激光与粒子束,1997, 9(2): 265-270.[7]谢家麟,赵永祥著,速调管群聚理论,北京:科学技术出版社,1960, 82-124.[8]黄华,王平山,甘延青,等.L波段相对论速调管输入腔研究.强激光与粒子束,1997, 9(4): 573-577. -
