MOSFET的高频热噪声
HIGH-FREQUENCY THERMAL NOISE IN MOSFET
-
摘要: 从 A.Van der Ziel(1976)提出的电流电压方程出发,导出一个归一化扰动量微分方程。将归一化扰动量的傅氏变换按j的幂级数形式展开并且求解,得到在漏、栅端扰动量傅氏变换的各阶解析解,同时也就得到了漏、栅极的噪声电流谱和相关系数,在结论中,指出了方程的高阶解对噪声谱的影响。
-
关键词:
Abstract: Starting from the current-voltage equation given by A. Van der Ziel (1976), a dif-ferential equation of the normalized fluctuation is developed. Expanding the Pourier transform of the fluctuation into a power series in the parameter j and solving the equation developed, we get all order analytical solutions of the Fourier transform of the fluctuation in drain and gate. The spectral desities of noise current of drain and gate as well as the correlation coefficient are also obtained. The effect of the higher order solutions of the equation on the noise spectra is shown in the conclusion. -
A. Van der Ziel, Proc.IEEE, 51(1963), 461.
