X波段低噪声高阶模式介质稳频振荡器
X-BAND DRO WITH LOW PHASE NOISE OPERATING IN HIGH-ORDER MODE
-
摘要: 本文采用介质谐振器(DR)的高阶模式(TE021模式),研制出振荡频率为10.7GHz的并联反馈型介质稳频振荡器(DRO).由于可以获得很高的有载Q值,振荡器具有良好的相位噪声性能(偏离载频20kHz处-88dBc/Hz)。Abstract: With higher-order mode (TE021 mode) of the Dielectric Resonator(DR), a parallel feedback-type Dielectric Resonator Oscillator(DRO) operating at 10.7GHz is reported. Because of the high loaded quality factor of DR, the oscillator shows excellent phase noise performance (about 88dBc/Hz at 20kHz offset).
-
潘庆为.双介质谐振腔FET振荡器.推广与应用微波介质谐振器学术交流会论文集.西安:1987, 95-99.[2]费元春,陈世伟,杨士仕,等.徽波固态频率源.北京:国防工业出版社,1994, 52-55.[3]Kajfez D, Guillon P. Dielectric Resonators US: Artech House, Inc. 1986, 65-110.[4]Gross W, Glandorf F J. Design of series feedback millimeter wave oscillators employing whispering gallery mode dielelctric resonators, Proc. EUMC. (Helsinki): 1992, 491-496.[5]Hafner E. The effects of noise in oscillators, Proc. IEEE, 1966, 54(2): 233-237. -
