适于瞬态分析的等效小参量法及其在PWM开关变换器中的应用
EQUIVALENT SMALL PARAMETER METHOD FOR TRANSIENT ANALYSIS AND ITS APPLICATION IN PWM SWITCHING CONVERTERS
-
摘要: 等效小参量法是一种改进的扰动技术,适于求取强非线性系统的周期解.最近已成功地将它应用于开关变换器的稳态分析.本文根据该方法的基本思想和求解程序,提出适于瞬态分析的等效小参量法,并用它分析PWM开关变换器的瞬态过程.本文方法计算量小,精度较高.Abstract: An improved perturbation technique (equivalent small parameter method) proposed in a recent paper (Int. J. Electronics, 1989, 67(3): 403-414) has been successfully applied to steady-state analysis of DC-DC PWM switching converters. This paper extends the algorithm to transient analysis of a broader class of non-linear systems. As an example, the transient respoase of a PWM switching converter is analyzed to demonstrate its simplicity and accuracy.
-
Hayashi H. Nonlinear oscillations in physical systems. Princeton, NJ: Princeton University Press, 1964, Chapter 1.[2]Sanders S R, Noworolski J, Liu X.et al. Generalized averaging method for power conversion circuits. IEEE Trans. on Power Electronics, 1991, PIr6(2): 251-259.[3]Qiu S S(丘水生)，Filanovski M I. Calculation of steady-state oscillations in non-linear circuits[J].Int. J. Electronics.1989, 67(3):403-414[4]丘水生.非线性网络与系统.成都:电子科技大学出版社,1990.[5]丘水生.分析开关变换器的一种新方法.华南理工大学学报,1994, 22(3): 74-81.[6]林波涛,丘水生.PWM开关变换器的符号分析.电子学报,1996, 24(9): 83-87.[7]Krein P T, Bentsman J, Bass R. et al. On the use of averaging for the analysis of power electronic systems. IEEE Trans, on Power Electronics, 1990, PE-5(2): 182-190.[8]Middlebrook R D, Cuk S. A general unified approach to modelling switching-converters power stages. IEEE Power Electronics Specialist Conference Record, Cleveland: 1976, 18-34.[9][9][10]卢树铭等.矩阵理论及应用.沈阳:辽宁科学技术出版社,1989,第六章. -
