一种性能优良的和频上变频器
HIGH-PERFORMANCE SUM-FREQUENCY UPCONVERTER
-
摘要: 本文介绍一种结构新颖、性能优良的8mm波段和频上变频器。变频器的变频损耗为2.9dB;1dB压缩点输出功率1.34mW;和频信号小于1mW范围内,变频器具有极好的线性;和频信号比杂散组合频率谱线强30dB以上;各端口隔离度均大于40dB。
-
关键词:
- 上变频器; 双脊波导; 变容管
Abstract: A new 8 mm high-performance sum-frequency upconverter is described. Ttsconversion loss is 2.9 dB; its output power is 1.34mW at 1 dB compression point. As the power of sum-frequency signal below 1mW, the upconverter shows a very good linearity. Sum-frequency signal is 30 dB higher than stray spectrum. The isolation of each port is over 40 dB. -
邓绍范等,八毫米波段和频上变频器研究报告,哈尔滨工业大学,哈尔滨,1987年.[2]Shizuo Mizushina et al., IEEE Trans. on MTT. MTT-25(1977)12, 1131-1134.[3]L.T. Yuan, IEEE Trans. on MTT, MTT-25(1977)12, 1048-1054.[4]徐德忠等,八毫米波段和频上变频器测试报告,航空航天部弟二研究院计量研究所,北京,1987年. -
