同一平面缝阵天线实现宽窄两种波束的方法和馈电网络
METHODS OF REALIZING WIDE AND NARROW DUAL BEAMS ON ONE PLANAR SLOT ARRAY AND FEED NETWORKS
-
摘要: 本文提出了同一平面缝阵天线实现宽窄两种波束并能进行转换的方法。进行了理论分析,给出了馈电网络各参数之间的关系,对波瓣图进行了计算,理论和实验结果基本一致,该方法已在实际中使用。
-
关键词:
- 缝阵天线; 平面缝阵天线; 天线馈电网络
Abstract: The methods to realize wide and narrow beams by one planar slot array and feed networks are proposed, in which the theoretical analysis and the relations between parameters of feed networks are given. Theoretical results agree with the experimental data quite well. This methods has been applied in practice. -
W.L.Teeter, K. R. Bushore, IRE Trans. on MTT, MTT-5(1957), 225.[2]赵连贵,秦允锦,圆口径单脉冲平面缝阵天线,空军第一研究所内部资料.[3]L. F. Deerkoski, et al., U. S. Patent, 3,965,475. -
