里德型变容二极管参量放大器的计算机辅助设计
COMPUTER-AIDED DESIGN OF PARAMETRIC AMPLIFIERS WITH READ-TYPE VARACTORS
-
摘要: 本文用一个计算机程序研究了实际的高低掺杂变容二极管的工作情况,确定该器件作为参放的优劣程度。还给出了工作频率范围、偏置电压、泵浦功率以及相应的负阻值等主要的电气参量,从而为参放的结构设计提供了依据。
-
关键词:
Abstract: In this paper, a computer program is made for studying actual parametric amplifiers with Hi-lo doping varacters. The main parameters of the parametric amplifier, e.g. working frequency, bias voltage, pumping power and negative resistaaee are obtained with this program, then a basis for the desiga of paramatric amplifiers is provided. -
D.F. Peterson and G. I. Haddad, IEEE Trans. on MTT,MTT-28 (1980), 945.[2]P.Penfield and R. P. Rafuse, Varactor Application, The MIT Press,Cambridge, MA, 1962.[3]L.A. Blackwell and K. L. Kotzebue, Semiconductor-diode Parametric[4]Amplifiers, Prentie-Hall Inc. Englewood Cliffs, NJ, 1961.[5]宋文淼, 半导体杂志, I983年,第5期,第17页. -
