宽带改型B夹层天线罩罩壁结构
BROADBAND MODIFIED B SANDWICH AS RADOME S LAYER STRUCTURE
-
摘要: 本文提出了一种有效的宽带改型B夹层天线罩罩壁结构。这种结构,在0～70的入射角范围内,0～40GHz带宽内,功率传输系数优于80.0％,且垂直极化与水平极化之间的插入相位延迟的差异极小。
-
关键词:
- 天线罩; B夹层; 传输特性
Abstract: An effective broadband modified B sandwich as radome s layer structure is adopted. The power transmission coefficient of this sandwich is over 80% under large incident angle (0-70) and broadband (0-40GHz). The difference of insertion phase delay (IPD) between perpendicular polarization and parallel one is very small. -
Bassett H L, Bodaar D G. Broadband Radome Techniques, AD-A085663. 1974.[2]Erast J S. Broadband Metallic Radome, AFAL-TR-79-1142. 1979.[3]Rope E L, Tricoles G. Broadband Millimeter Wave Radome, Proceedings of the 15th Symposium on Electromagnetic Windows. Georgia, U. S. A.: 1980, 93-95.[4]卡普伦 B A.超高频天线罩(上).北京:八机部三院三部,1980,第2.8节.[5]Cornbleet S. Microwave Optics--The Optics of Microwave Antenna Design, London, New York. San Francisco: Academic Press, 1976, 162-167.[6]王笃祥.宽频带天线罩技术分析.内部报告.南京:航空航夭工业部八五一一研究所,1989, 14-15.[7][7][8]王笃祥.宽带导弹天线罩分析和计算:[硕士论文].南京:航空航天工业部八五一一研究所,1990,67-68.[9]Conti D A. Broadband Radome Considerations. Proceedings of the 18th Symposium on Electromagnetic Windows, Georgia, U. S. A.: 1986, 91-101. -
