BJT动态模型参数相关提取方法
THE CORRELATIVE EXTRACTION METHOD FOR BJT DYNAMIC MODEL PARAMETERS
-
摘要: 本文提出一种利用双极晶体管(BJT)静态和动态参数相关性,准确提取器件动态模型参数的新方法,并验证了该方法的可行性和实用性。
-
关键词:
- 双极晶体管; 器件模型; 参数表征
Abstract: A new method of extracting BJT dynamic model parameters is proposed by using the correlation between dynamic and static model parameters. Finally, the feasibility and utility of the method are demonstrated. -
Zuberek W M, et al. IEE Proc.-G., 1994, 141(1): 129-134.[2]Kuntman K. Int. J. of Electronics, 1993, 73(4): 541-552.[3]Park J S. IEEE Trans. on ED, 1989, ED-36(1): 88-95.[4]Liou J I, Yuan J S. IEE Proc.-G., 1991, 138(1): 97-102.[5]Hafizi M E, et al. IEEE Trans. on ED, 1990, ED-37(10): 2121-2129.[6]Gummel H K, Poon H C. Bell Sys. and Tech. J., 1970, 49(5): 827-852.[7]郝跃,贾新章.电子学报,1989, 17(6): 105-107. -
