开槽耦合型H01H0n模式变换器
A NEW TYPE OF H01H0n MODE TRANSDUCER
-
摘要: 本文叙述了一种新型的开槽耦合型H01H0n 模式变换器的设计原理、制作技术以及在8mm波段的实测结果。它显示了宽带特性。在32-37GHz的频带内,输入驻波比低于1.1;变换损耗低于1dB;杂模H01幅度低于－15dB。
-
关键词:
- 微波元件; 模式变换器; 迴旋管
Abstract: The design, constrution and experimental results of a new type of H01H0n , mode transducer which wall is gradually slotted are discribed. It is a wideband mode transducer. Its voltage standing wave ratio is less them 1.1; its conversion loss is less then 1dB, and its amplitutc of the unwanted mode (H01 ) is lower then 15dB -
刘刚,新型复合开放腔回旋管注波互作用计算,硕士学位论文,北京中国科学院电子学研究所,1988年8月.[2]Y. Y. Lan, L. R. Bernett, Ins. J. Infrared and Millimeter Waves, 3 (1982) 5, 619-644.[3]N. M. Kroee, W. E. Lamb; Appl.Phys., 19(1948) 2, 166-186. -
