双渐变技术减小 AM-PM转换系数的初步研究
AN INVESTIGATION INTO REDUCING AM-PM CONVERSION COEFFICIENT BY THE DOUBLE TAPER HELIX TECHNIQUE
-
摘要: 行波管欠压工作能减小AM-PM转换系数。因此在行波管中加入一段工作于该状态的慢波线应能改善AM-PM转换特性。由此引出了所谓双渐变技术。 本文对该技术作了初步分析,实际制管证明了该技术不仅能提高电子效率,而且能改善AM-PM转换特性。并且还具有多电平工作、降压效果好等优点。本文还总结了一套小信号设计方法。
-
关键词:
Abstract: The eonversion coefficient of a TWT can be reduced, when it works at under-voltage condition. Therefore if a section of helix which works at under-voltage condition is added to a TWT, the improvement of AM-PM eonversion coefficient can be expected,then a doubl taper helix technique is developed.This paper describes the double taper helix technique and presents a small signal design method. The actual TWT which uses the double taper helix proves that it not only raises the electron efficiency, but also improves the AM-PM conversion coefficient. Further experiment shows that this technique has other advantages, such as operation at two or three power levels and good depressed collector characteristics. -
周文表,过压提高均匀螺距行波管效率的大信号计算,中国科学院电子学研究所内部报告,1979年.[5]周文表,电子学通讯,2(1980), 72. -
