信号时域提取方法结合时域有限差分法分析传输线馈电的微波元件
ANALYSIS OF MICROWAVE COMPONENTS FED BY THE TRANSMISSION LINES WITH A METHOD OF SIGNAL EXTRACTION IN TIME DOMAIN IN COMBINATION WITH FDTD
-
摘要: 本文提出了一种信号时域提取方法,对于非色散传输线馈电的微波元件,利用这一方法,从时域模拟获得的总场响应中提取馈线参考面上的时域入射波和反射波,进而得到其频域特性。与传统方法相比,它可以避免通过时域有限差分法直接求解入射波和反射波,因此可以减少计算时间和计算机内存。矩形微带天线的数值模拟表明,这种方法的计算精度与传统方法完全一致。Abstract: A method of signal extraction in time domain is proposed in this paper, by means of which, the time-domain incident wave and reflected wave on the reference plane of the feeder can be extracted from the total-field responses obtained from the time-domain simulation for the microwave components fed by the nondispersive transmission lines, furthermore, its frequency-domain parameters can also be acquired. By comparison with traditional methods, it can avoid to directly compute the time-domain incident wave and reflected wave using the finite-difference time-domain method, so computation time and storage can be reduced. The numerical simulations of rectangular microstrip antenna show that the computation precision of this method is the same as that of traditional methods.
-
Yee K S. Numerical solution of intial boundary value problems inivolving Maxwells equations in isotropic media. IEEE Trans. on AP, 1966, 14(3): 302-307.[2]Reineix A, Jecko B. Analysis of microstrip patch antennas using finite difference time domain method. IEEE Trans. on AP, 1989, 37(11): 1361-1369.[3]Sheen D M, Ali S M, Abouzahra M D, Kong J A. Application of the three-domainsional finitedifference time-domain method to the analysis of planar microstrip circuits[J].IEEE Trans. on MTT.1990, 38(7):849-857[4]Ciampolini P, Roselli L, Stopponi G. Integrated FDTD and solid-state device simulation[J].IEEE Microwave and Guided Wave Letters.1996, 6(11):419-421[5]袁伟良,梁昌洪.波导不连续性的时域分析.西安电子科技大学学报,1997,24(4):453-458[6]Tsai H-S, York R A. FDTD analysis of CPW-fed folded-slot and multiple-slot antennas on thin substrates. IEEE Trans. on AP, 1996, 44(2): 217-225.[7]Mur G. Absorbing boundary conditions for the finite-difference approximation of the time-domain electromagnetic field equations. IEEE Trans. on EMC, 1981, 23(4): 377-382.[8]Piket-May M, Taflove A, Baron J. FD-TD Modeling of digital signal propagation in 3-D circuits with passive and active loads[J].IEEE Trans. on MTT.1994, 42(8):1514-1523[9]袁伟良,梁昌洪.FDTD分析微带结构的一种馈源模型.1997全国微波年会会议(下册),青岛:1997,481-483. -
