开关电容振荡器的起振和幅值稳定的研究
STUDY OF START-OSCILLATION AND AMPLITUDE-STABILIZATION OF SC OSCILLATORS
-
摘要: 本文讨论了开关电容振荡器(SCO)的起振和幅值稳定问题。提出了SCO的起振和幅值稳定的新方法。给出了稳定性好的幅值控制电路。在多相SCO的设计中,幅值控制电路的复杂程度不随振荡器的相数增加而增加。实验结果与理论相符。
-
关键词:
- 开关电容振荡器; 起振; 幅值稳定
Abstract: How to start oscillation and how to stabilize amplitude in SC oscillators are discussed. New methods for start-oscillation and amplitude-stabilization of SC oscillators are presented. The control circuitry with good stability for amplitude-stabilization is given. It is shown that the complexity of the amplitude-stabilization circuitry does not increase as the number of oscillator phases in the multiphase oscillator increases. The experimental results are in agreement with the presented theory. -
杨永明,电子科学学刊,10(1988)6, 491-500.[2]W. B. Mikhae, S. Tu, IEEE Trans. on CAS, CAS-31(1984), 280-291.[3]R. Gregorian, K. R. Matin, G. C. Temes, Proc. IEEE, 71(1983) 8, 941-965.[4]E. Vittoz, IEEE J. of SC, SC-14 (1979) 3. 644-647.[5]R. P. Colbeck, IEEE J, of SC, SC-19 (1984) 6, 996-998.[6]P. E. Fleischer, A. Ganesun, K. R. Laker, IEEE J. of SC, SC-20 (1985) 2, 641-647.[7]G. C. Temes.[J].Electron. Lett..1978,14:9- -
