结合保角变换的优化模拟镜象法解多种截面形状同轴线的特性阻抗
THE SOLUTION OF THE CHARACTERISTIC IMPEDANCE OF ARBITRARILY SHAPED COAXIAL TRANSMISSION LINES BY USING THE OPTIMIZED SIMULATED IMAGE-CONFORMAL MAPPING METHOD
-
摘要: 介绍一种计算多种截面形状同轴线的新方法结合保角变换的优化模拟镜象法。此法计算量小、精确度高,并能进行误差范围计算。列出对内圆外方、偏心内圆外方和内带形外圆等九种同轴线特性阻抗的计算结果并与其它文献结果进行了比较。
-
关键词:
- 保角变换; 优化模拟镜象法; 特性阻抗
Abstract: A new method, the optimized simulated image method in combination with conformal mapping, is introduced to calculate the characteristic impedance of arbitrarily shaped coaxial transmission lines. It is of small calculating amount and high accuracy, and the error range can also be estimated. The calculating results of the characteristic impedances of nine coaxial lines, such as concentric, eccentric circular inner and square outer conductors, strip inner and circular outer conductors, are tabulated and compared with data from other papers. -
Chow Y L, et al. Proc. IEEE, 1979, 26(1):123-125.[2]方大纲,刘次由.微波理论与技术,北京:兵器工业出版社,1987,第四章.[3]Pan S. IEEE Trans. on MTT, 1988, MTT-36(5):917-921.[4]徐善驾,等.电子科学学刊,1992,14(4): 396-403.[5]Wheeler H A. IEEE Trans. on MTT, 1980, MTT-28(2):73-83.[6]林为干.电磁场工程.北京:人民邮电出版社,1980,第一章.[7]Gunston M. A. Microwave Transmission Line Impedance Data, New York: Van NostrandReinhold, 1972, Chap. 4.[8]Oberhettinger F, et al. Applications of Elliptic Functions in Physics and Technology.New York: Springer Verlag, 1949.[9]潘生根.电子学报,1988,16(6): 15-20.[10]Lin W. IEEE Trans. on MTT, 1982, MTT-30(11):1981-1988.[11][11][12]Sheahadri T K, Rajaian K. Proc[J].IEEE.1982, 70(1):82-83[13]Riblet H J. IEEE Trans. on MTT, 1983, MTT-31(10): 841-844.[14]Lin W. IEEE Trans. on MTT, 1985, MTT-33(6):545-555.[15]潘生根.中国科学,1986,29(4): 999-1008.[16]Epele L N, et al. Proc[J].IEEE.1984, 72(2):223-224 -
