双极模拟集成电路的参数统计性分析
THE PARAMETER STATISTICAL ANALYSIS FOR BIPOLAR ANALOGOUS INTEGRATED CIRCUIT DESIGN
-
摘要: 本文给出了实现双极模拟集成电路参数统计相关性分析的步骤和方法,提出了含对称参数分析的双参数(BF,RS)统计分析方法。实例分析和对比表明,该方法适于模拟集成电路的分析和设计。Abstract: The method and procedure for realizing parameter statistical correlation analysis of bipolar analongous integrated circuits are given, and a statistical method of double parame-ters (BF, Rs) with some symmetrical parameters is suggested. Based on the comparision and analysis of the circuits, it is shown that the method can be used to analyse and design bipolar analogous integrated circuits.
-
D. A. Divakar, IEEE J. of SC, SC-12(1977)10, 552-559.[2]P. Balaban, IEEE Trans. on CAS, CAS-22(1975)2,100-108.[3]S. Inohira, IEEE Trans. on CAD, CAD-4(1985)4, 621-627.[4]J. Logan, Bell Syst. Tech. J., 50(1971)4, 1105-1174.[5]郝跃,姚立真等,电子科学学刊,10(1988)6,501-506. -
