任意E面膜片不连续性及其在毫米波滤波器中的应用
ARBITRARY E-PLANE STRIP DISCONTINUITIES AND THEIR APPLICATION TO MILLIMETER WAVE FILTERS
-
摘要: 本文利用矩量法和一般的网络分析技术分析了各种E面膜片不连续性。通过引入广义波导概念,自然地考虑了膜片的厚度效应,使问题的分析得到了统一。文中给出了一组正面膜片不连续性的等效电路参量曲线,基于这些曲线,设计和试制了二个W波段E面带通滤波器,实验结果与设计指标符合较好。Abstract: Various E-plane strip discontinuities are analyzed by the moment method and generalized network analysis technique. By introducing an idea of wide-sense waveguide, a united treatment of such problems is realized, and the thickness of the strip is taken into account. A set of curves for the equivalent circuit parameters of E-plane strip discontinuities are given. Two E-plane bandpass filters are designed and tested at W-band. Experimental results agree well with theoretical predictions.
-
Y. Konishi, et al., IEEE Trans. on MTT, MTT-22(1974), 869-873.[2]李嗣范,陈忆元,中国科学A辑,1982年,第9期,第857-866页.[3]F. Arandt, et al., IEEE Trans. on MTT, MTT-30(1982), 155-163.[4]Y. C. Shih, et al., IEEE Trans on MTT, MTT-31(1983), 135-142.[5]Rong Aosheng, Li Sifan, IEEE MTT-S Int Microwave Symp Digest, U. S. A., 1987, 721-724.[6]R. F. Harrington, Time Harmonic Electromagnetic Fields, New York, McGraw-Hill, 1961.[7]K. C. Gupta, et al., Computer-Aided Design of Microwave Circuits, Dedhan, MA, Artech House, 1981.[8]Li Sifan, Rong Aosheng, 12th Int. Conf. Infrared and Millimeter Waves, U. S. A., 1987, 251-252. 期刊类型引用(1)
