实现Ricatti变换的有限元网格的自动剖分
AUTOMATIC GENERATION OF FINITE ELEMENT MESHES FOR THE REALIZATION OF RICATTI TRANSFORMATION
-
摘要: 本文探讨了用单矩量法求解任意截面介质柱体电磁散射问题的计算技术,在用有限元法求解数学圆内部的场时,从计算程序上实现了解线性方程组的Ricatti变换法,以矩形柱体为例,采用了实现Ricatti变换的有限元网格的自动剖分技术,证明采用这些技术和方法在减少所占计算机内存、节省计算时间和简化有限元法的前处理工作等方面有显著效果,并为编制通用计算程序提供了条件。
-
关键词:
Abstract: Some computing techniques of the unimoment method for solving electromagnetic scattering problems of a dielectric cylinder with arbitrary cross section are investigated. Rieatti transformation is used in solving the set of linear equations for finding the internal fields inside the mathematical circle and its computer program is realized. With the exam-ple of a rectangular cylinder, automatic generation of finite element mesh realizing Ricatti transformation is illustrated. It is seen that by using the above techniques and methods, effects in saving the memory capacity and the computing time of the computer and in simplifying the previous procedure of the finite element method are obvious; and also the convenience for the formation of a universal computer program is provided. -
K. K.Mei IEEE Trans. on AP,AP-22(1974),760.[2]R .E.Stovall and K. K. Mei, IEEE Trans. on AP, AP-23(1975), 335.[3]Shu-Kong Chang and K. K. Mei, IEEE Trans. on AP, AP-24(1976), 35.[4]孙乃华,华东师范大学学报(自然科学版),1982年,第1期,第35页.
