含全感割集多线圈耦合网络回路方程的直接形成算法
ALGORITHMS FOR DIRECTLY FORMULATING LOOP EQUATIONS OF A MULTI-WINDING COUPLED NETWORK WITH ALL INDUCTOR CUT-SETS
-
摘要: 在本文作者之一的前文(1991)基础上,将尽可能多的耦合支路以及所有电流源支路选为连支,从而在不进行矩阵运算的情况下,可以根据网络的拓扑结构和元件参数直接建立含有全感割集多线圈耦合网络的以连支电流为待求量的回路电流方程。并用实例进行了说明。Abstract: By choosing the highest possible inductively coupled branchs and all current sources as links, the loop equations are directly formulated. The network may contain all-inductor cut-sets. The order of the presented loop equations is less than that of the modified modal approach equations. An example is given.
-
雷海亮.电子科学学刊,1991,13(4): 365-371.[2]Len O Chua, Lin Penmin. Computer Aided Analysis of Electronic Circuit -Algorithms Computational Techniques. Englewood Chiffs, NJ: Prentice-Hall, Inc. 1975, 4-5.[3]Ho C W. IEEE Trans. on CAS, 1975, CAS-22(6): 504-509.[4]雷海亮,等.山东工业大学学报,1985,(3): 63-71. -
