双向负阻晶体管张弛振荡器分频锁相特性的研究
FRACTIONAL PHASE-LOCKING OF A RELAXATION OSCILLATOR BY PERIODICALLY APPLIED IMPULSES
-
摘要: 本文用简单模型描述了双向负阻晶体管(BNRT)张弛振荡器在周期冲激作用下的分频锁相特性。对于任何分数p/q,给出了在参数空间中分频锁相区的普遍的分析表达式。对于BNRT张弛振荡器进行了分频锁相实验,实验结果与计算相符,说明理论分析是正确有效的。
-
关键词:
- 张弛振荡器; 双向负阻晶体管; 分频锁相
Abstract: A simple model is used to describle the fractional phase-locking of a relaxation oscillator by periodically applied impulses. For any definite fraction p/q, analytic expressions are derived for the phase-locking region in the parameter space. Experimental results for a bidirectional negative resistance transistor (BNRT) relaxation oscillator agree with the computed ones. -
李凤银,周旋等,半导体学报,5(1985)6,685-687.[2]朱照宣,余道衡,科学通报,32(1987)1,22-24.[3]Tracy Allen, IEEE Trans. on CAS, CAS-30(1983)9, 627-632.[4]余道衡,朱照宣,电子科学学刊,9(1987)2,176-180. -
