电磁随钻测量的电激励模式的分析
AN ANALYSIS OF THE ELECTRICAL EXCITATION MODE OF EM-MWD
-
摘要: 本文提出一种电磁随钻测量的电激励模式的分析方法。这一方法可计算电磁随钻测量研究中的重要参数,如地面信号场强分布规律及其与工作频率的依赖关系,发射机构的输入阻抗等,从而为随钻测量系统的总体设计提供基本的依据。用这一方法对试验模型和现场试验进行的计算与试验结果很好符合。
-
关键词:
- 电磁随钻测量; 电磁散射; 电激励模式
Abstract: A method for analyzing electrical excitation mode of electromagnetic measurement while drilling (EM-MWD) is proposed. By this method, a lot of calculations for EM-MWD has been done, and some very important data have been obtained, in which the electric field intensity distribution patterns on the earth s surface, the dependent relations of electric field intensity upon the frequency and the input impedance of the transmission equipment are included. All of the calculated results agree well with that of the laboratory test and the shallow well test. -
K.M.Chen, Interaction of Electromagnetic fields with biological bodies in Research Topics in Electromagnetic Wave Theory, Ed. J.A. Kong, John WileySons Inc. (1981).[2]K.M.Chen, Proc. IEEE, 65(1977), 1202.[3]陈志雨,靳小州,电磁随钻测量,中国科学院电子学研究所内部试验报告,1988年.[4]中国科学院电子学研究所随钻测量电磁波论证组,电磁随钻测量现场试验报告,1998年.
