高模式纯度H○02波波型变换器
A HIGH PURITY H○02 WAVE TRANSDUCER
-
摘要: 本文所述的H○02波波型变换器由中心激励型H10H○02波波型变换器、H02波过渡器和H10波过渡器三部分组成。文中对上述有关部分分别列出了设计公式,给出了计算结果。在8mm波段实测的结果表明:这种变换器在 3238 GHz频带内,对H○01波的抑制在 30dB以上。
-
关键词:
Abstract: The H○02 mode transducer described in the paper consists of three parts: centre-excited type H10H○02 transdueer, H○02 mode taper and H10 mode taper. The design formulae of the relative parts are derived and the results obtained are given. The practical measurement at 8 mm band has been completed. It shows that the rejection to H○01 mode of the transducer is about 30 dB in 32-38GHz. -
Shuich Sbindo, IEEE Trans.on MTT, MTT-24(1976), 525.[3]Kunio Hashimoto, IEEE Trans. on MTT, MTT-24(1976), 25.[4]Nobus Suznki, R. E. C. L. 24(1976), 429.[5]黄宏嘉,微波原理,卷Ⅱ, 科学出版社,1963年,第430页.[6]L. Solymar, PIEE, 106(1959) Part B Suppl. No. 13, p. 121 -
