采用圆锥形陶瓷大功率微波输出窗的模拟分析
The Simulation of the Conical-Shaped-Alumina Ceramic Pill-Box RF-Window
-
摘要: 该文尝试利用一种圆锥形陶瓷盒形输出窗，改善大功率微波输出窗的匹配特性、功率承受性能和热耗散能力。采用Ansoft HFSS三维计算软件分析了此类陶瓷输出窗的基本电气和热耗散性能，对大功率输出窗的工程设计很有意义。Abstract: In this paper, a conical-shaped alumina ceramic pill-box windows is investigated to improve the output properties of the RF-window, such as matching characteristic, the maximum power transmission capability and heat dissipation. The basic electronical characteristic and heat dissipation have been analyzed with Ansoft HFSS software, which is helpful to the engineering design of RF-window.
-
