有限厚度衬底非对称共面线的基本参数
BASIC PARAMETERS OF ASYMMETRICAL COPLANAR LINES WITH FINITE SUBSTRATE THICKNESS
-
摘要: 本文首先利用保角变换法分析了自由空间中的非对称共面线,得到了其严格解,然后给出了任意多层有限厚度衬底非对称共面线的有效介电常数、单位长度线电容、特性阻抗和导波波长的闭合形式的解析表达式。这些分析对微波毫米波集成电路的设计有意义。Abstract: In this paper, asymmetrical coplanar lines in free space are analyzed using confor-mal mapping techniques, and the exact solutions are obtained. Analytic closed-form expressions for the effective dielectric constant, the capacitance per unit length, the characteristic impedance and the wavelength of guided wave for asymmetrical coplanar lines with multi-layered finite substrate thickness are obtained. The analyses are useful for the (M)MIC s designs.
-
Kneppo I, Gotzman J. Basic parameters of nonsymmetrical coplanar lines. IEEE Trans. on MTT, 1977, MTT-25(8): 718.[2]Gevorgian S S. Asymmetric coplanar-strip transmission lines for MMIC and integrated optic applications[J].Electron. Lett.1990, 26(22):1916-1917[3]Cohn S S. Slot line on a dielectric substrate. IEEE Trans. on MTT, 1969, MTT-17(5):768-778.[4]Wen C P. Coplanar waveguide: A surface strip transmission lines suitable for nonreciprocal gyromagnetic device. IEEE Trans. on MTT, 1969, MTT-17(6):1087-1090.[5]Veyres C, Hanna V F. Extension of the application of conformal mapping techniques to coplanar lines with finite dimensions. Int. J. Electron.1980, 48(1): 47-56.[6]Hanna V F. Finite boundary corrections to coplanar stripline analysis[J].Electron. Lett.1980, 16(15):604-606[7]Gevorgian S S. Basic characteristics of two layered substrate coplanar waveguides[J].Electron. Lett.1994, 30(15):1236-1237[8]Bedair S S. Characteristics of some asymmetrical coupled transmission lines. IEEE Trarvs. on MTT, 1984, MTT-32(1):108-110. -
