任意横截面形状同轴线的高次有限元分析
HIGH-ORDER FINITE-ELEMENT ANALYSIS OF VARIOUS COAXIAL LINES WITH ARBITRARY CROSS-SECTIONS
-
摘要: 本文用高次有限元分析了任意横截面形状同轴线特性阻抗;给出了一个用二次元求解同轴线特性阻抗的通用程序。由于提出了一种便于编制通用程序的计算机自动区域剖分方法,使整个分析过程十分简便有效,大大提高了解题效率。文中对十余种不同横截面形状同轴线特性阻抗的计算,有力地证实了该程序的可靠性,通用性和准确性。同时,在数值分析的基础上,对高次元的解题效能进行了讨论。
-
关键词:
- 同轴线; 特性阻抗; 高次有限元分析
Abstract: The high-order finite-element method is used for analyzing the characteristic impedances of the coaxial lines with arbitrary cross-sectons. A standard program with second order element analysis for calculating the characteristic impedances of various coaxial lines is developed. A computer automatic division technique is proposed to faciliate the development of the general program. As a result, the whole analysis procedure becomes simple and the solusion efficency raises tremendously. The calculations of the... -
Lin Weigan, IEEE Trans.on MTT, MTT-30 (1987,) 11, 1981-1988.[2]Pan Shenggen, IEEE Trans. on MTT, MTT-36 (1988)5,917-921.[3]林为干,物理学报,30(1981)1，12-21.[4]林为干,微波理论与技术,科学出版社,北京,1979年.[5]H.J.Rilblet, IEEE Trans. on MTT, MTT-23 (1975)8,714-715.[6]Wulu Chang, Frequenz, 43 (1989) 10, 271-276.[7]徐善驾,电子学通讯, 4(1982)4, 222-234.[8]徐善驾,彭松村,通信学报,6(1985)4,62- 69. -
