多注速调管一种新型大功率微波放大器
MULTIBEAM KLYSTRON-A NEW TYPE OF HIGH POWER MICROWAVE AMPLIFIER
-
摘要: 本文介绍了一种新型大功率微波放大器多注速调管。扼要地评述了多注速调管的发展概况,详细地介绍了基于速调管谐振腔基模的多注速调管的工作原理和主要特点。研究了多注速调管参数对工作带宽和输出功率的影响。给出了多注速调管的功率限制。指出了多注速调管的关键技术问题和发展趋势。
-
关键词:
- 多注速调管; 导流系数; 谐振腔基模
Abstract: A new type of high power microwave-multibeam klystron has been described. The development of multibeam klystron is commented on briefly, the principle and main characteristics of multibeam klystron based on the fundamental mode of klystron cavity are given in detail. The effect of the parameters of multibeam klystron on the operating bandwidth and output power has also bean studied, and the power limitation is given in this paper. Finally, the key technical problems and trend of multibeam klystron are pointed out. -
Kovalenko V F.[J].Anthers Certificate, No. 72756, Class 21, 13, Applied on Dec.1940,31:-[2]Bernier J, Patent No. 992853, Sept. 15, 1944, dance.[3]Boyd bf R, et al.,IRE Trans. on ED, 1962, ED-9(3): 247.[4]Pohl VW J, et al.,IRE Trans. nn ED, 1965, ED-12(6): 351-368.[5]Branch G M, et al., AD-807 515/2, AD-812 190/7, AD-815 777/8, Sept. 1966-March 1967.[6]Gelvich E A, et al., IEEE Trans. on MTT, 1993, MTT-41(1): 15-19.[7]Pobedonostsev A S, 1993 IEEE MTT-S, Digest, 1993, 1131-1134.[8]Gelvich E A, et al., 1991 IEEE MTT-S, Digest, 1991, 1319-1329.[9]Faillon G, Technical Digest of IEDM, 1986, 784-786.[10]Bearzatto C, et al., ITG-Fachbericht, No. 120, 1992, 45-51.[11]Reod D W. 1988 Linear Accelerator Conference, 1988, 514-518.[12]Mourier G, European Patent EP O 440530 Al, 1991, 1-11.Mourier G, European Patent EP O 440529 Al, 1991, 1-13. -
