反射系数对行波调制器特性的影响
EFFECT OF REFLECTION COEFFICIENT ON THE TRAVELING WAVE MODULATOR PERFORMANCES
-
摘要: 本文分析了当电极传输线与终端负载阻抗不匹配时,Ti:LiNbO3行波调制器的调制特性.主要讨论了反射系数对调制器半波电压、带宽以及对时域波形的影响。
-
关键词:
- 行波调制器; 半波电压; 冲激响应
Abstract: The characteristics of Ti: LiNbO3 traveling wave modulator have been analyzed in this paper, taking into account the reflection coefficient of the terminator. The main emphasis of the present work is placed on the description of the effect of the reflection coefficient on the bandwidth, the half-wave voltage and the time domain response. -
Sueta T, Izutsu M. Integrated optic devices for microwave applications. IEEE Trans. on MTT, 1990, MTT-38 ( 5) : 477-482.[2]speed Ti:LiNb03 and semiconductor optical modulators. IEICE Trans., 1993, E76- C(2): 183-190.[3]姚德森,毛钧杰.导行波技术基础.湖南长沙:国防科大出版社,1987, 19-33.[4]Alferness R C. Waveguide electro-optic modulators. IEEE Trans. on MTT, 1982, MTT-30(8): 1121-1137.[5]Erasure D, et al. Time-domain analysis of phase-reversal travelling-wave integrated modulators[J].Electron. Lett.1986, 22(19):1024-1026 -
