关于电子回旋频率对单腔回旋管参数影响的实验研究
EXPERIMENTAL STUDY OF THE EFFECT OF ELECTRON CYCLOTRON FREQUENCY ON PARAMETERS OF CRM-MONOTRON
-
摘要: 本工作研究了在H02模二次回旋谐波工作的8mm单腔回旋管中,电子回旋频率磁场对振荡幅值、输出功率、工作频率、频谱、工作电压和振荡区等主要参数的影响。利用高稳定的电子回旋频率可使该类器件的频率稳定度达10-5量级,频谱宽度和频谱漂移小于1.5MHz。还为实际应用该类器件提供了有用的数据。
-
关键词:
Abstract: The effect of electron cyclotron frequency on the amplitude, output power, frequency, frequency spectrum, beam voltage and oscillatory region of the 8 mm H02 mode CRM-Mo-notron operating at second harmonic of the cyclotron frequency is studied. By keeping the electron cyclotron frequency in high stability, the frequency stability of the CRM-Mono-tron can reach 10-5, and the spectrum width and frequency drift are less than 1.5 MHz. Some useful data are provided for use of the CRM-Monotron. -
K. R. Chu, M. E. Read and A. K. Ganguly, IEEE Trans. on MTT, MTT-28(1980), 318.[5]刘盛纲,中国科学,11(1981), 1401.[7]廖正久,电子学通讯,6(1982), 365.[8]廖正久等,全国电子学会第三届年会论文集,1982年,第61页.[9]D. V. Kisel, G. S. Korrablev, V. G. Navelyev, M. I. Petelin and S. Y. Tsimring, Radio Engineering and Electronic Phys., 19(1974), 65.[11], 22(1979), 367. -
