波导加载腔的场计算
FIELD COMPUTATION OF WAVEGUIDE LOADED CAVITY
-
摘要: 本文基于边界元法(BEM),提出了一种新的计算波导加载谐振腔的谐振频率、外Q值和场分布的数值计算方法。计算表明,用BEM来处理波导加载腔这样的开放系统,具有计算时间短、机器内存少和精度高等优点。
-
关键词:
- 边界元法; 谐振频率; 外Q值; 场分布
Abstract: This paper presents a new numerical method, which is based on boundary element method (BEM), for the computation of resonant frequency, external Q value and field distribution of the waveguide loaded cavity. It is shown that BEM has mamy advantages as little computing time, less storage and high precision, etc. in solving the open system like waveguide loaded cavity. -
Kroll M N, Yu D U L. Computer determination of the external Q and resonant frequency of waveguide loaded cavities. Particle Accelerators, 1990, 34: 231-250.[2]Kroll M N, Xin-Tian Lin. Efficient computer determination of the properties of waveguide loaded cavities. SLAC-PUB-5296, 1990, July.[3]Hajime Igarashi, Yasuyuki Sugawara, TosMhisa Honma. A numerical computation of external Q of resonant cavities[J].IEEE Trans. on Magnetics.1995, 31(3):1642-1645[4]倪光正,钱秀英.电磁场数值计算,北京:高等教育出版社,1996,第8.3节.[5]李忠元.电磁场边界元素法.北京:北京工业学院出版社,1987,第3.3节.[6]张雪阳,曾余庚.Helmholtz方程的边界元解法.西安:西北电讯工程学院学报,1984, 18(4): 42-45. -
