非理想因素对基于CCⅡ全集成连续时间滤波器的影响
ANALYSIS OF NONIDEAL EFFECTS ON CCII-BASED FULLY INTEGRATED CONTINUOUS-TIME FILTERS
-
摘要: 本文分析了用CCII实现的积分器的误差函数。在此基础上,研究了由双积分器回路构成的基于CCII全集成连续时间带通滤波器;分析了中心频率p,和Qp,与误差函数幅值E和相位E之间的关系;探讨了CCII非理想因素对p,和Qp的影响。所得结论为设计基于CCII的MOSFET连续时间高阶滤波器提供了依据和改进途径。
-
关键词:
- 电流传输器; 全集成滤波器; 非理想分析
Abstract: The error functions of CCII-based integrators are analysed. On this basis, the fully integrated CCII-based continuous-time bandpass filters consisted of double integrator loops are studied, and the relationship between the centre frequency p and Qp and the magnitude E and the phase E of the error function is also discussed. The effects of nonideal CCII are considered in detail. The conclusions obtained may provide foundation and improvement for the design of CCII-based MOSFET continuous-time higher order filters. -
Sedra A S, Robert G W, Gohn F. IEE Proc.-G, 1990, 137(2):78-87.[2]Kumar U, Shukla S K. Microelectronics, J., 1989, 20(5):24-46.[3]Liu S I, Tsao H W, Wu J. IEE Proc.-G, 1991, 138(2):210-216.[4]陈莉,邱关源.基于非理想CCII电流模式积分器的性能分析,中国电子学会电路与系绕学会第十一届年会论文集.桂林:1993年11月,509-512.[5]Khoury J, Tsividis Y I. IEEE Trans. on CASE 1987, CAS-34(8):862-875.[6]Bingxue S, Khoury J, Tsividis Y I. IEEE Trans, on CAS, 1986, CAS-33(7):648-651.[7]Geiger R L. Bailey G R. IEEE Trans, on CAS, 1982, CAS-29(9):595-603. -
