旋转模式滤波器的设计
DESIGN OF A ROTATING MODE FILTER
-
摘要: 本文给出了扇形波导中的TE模场解。讨论了用扇形波导作为旋转模式滤波器的基本原理。介绍了这种滤波器的设计方法。给出了以TE03模工作时这种滤波器的实验结果。
-
关键词:
- 扇形波导; 旋转模式; 滤波器
Abstract: The solution of the electromagnetic field is given for TE mode in a infinite long fan-shaped waveguide. The basic principle of a rotating mode filter with fan-shaped waveguide is presented. The design method for the filter is discussed by a practical example. The good experimental result of the filter is reached for TE03 mode operation. -
Kimery H D，et al．Method and device for microwave sintering large ceramic articles．U．S．Patent， 4963709，Oct．16，1990．[2]Miyake S，et al．Focusing of high power millimterwave radiation by a quasi-optical antenna system． Int．J．Electronics，1991，70(5)：979-988．[3]Luo J，et al．Analysis of a mode filter．4th International Conference on Millimeter Waves and Far Infrared Science and Technology，Beijing：1996，230-932． -
