不对称传输线理论分析及实验研究
A Theoretical Analysis and Experimental Study of Asymmetrical Transmission Line
-
摘要: 该文在假设双线传输线两线上电流大小相等、方向相反的条件下,运用双线传输线理论思想,推得不对称(电流)双线均匀传输线的电压、电流关系。由此,文中给出了一种分析双线传输线变压器的实用、有效的方法,且理论结果与实测结果具有较好的一致性。Abstract: In this paper, by supposing the currents on the two lines are equal but opposite and with the application of bifilar transmission-line theory, the current-voltage relationships of the asymmetrical (current) bifilar even transmission line are obtained. It also gives a useful and effective analysis method for bifilar transmission-line transformer. The calculated values are in good agreement with the metrical values.
-
杨慎谦.短波多模多馈天线[J].电信技术研究,1994,(8):14-19.[2]张纪纲.射频铁氧体宽带器件[M].北京:科学出版社,1986:59-222.[3]Enzo Carpentieri. Model characterizes transmission-line transformers[J].Microwaves RF.1996,35(11):73-80 -
